HP315R

The HP315R is a metal, retrofit fire collar for concrete floor slabs and fire rated plasterboard, masonry and concrete walls.

For use with a range of pipe types (See below: click on a Report No. to access PDF).

N.B. All Fire Resistance Levels (FRLs) achieved on framed plasterboard wall systems are applicable to concrete or masonry walls of equal or greater thickness (AS1530.4: 2014 Section 10.12.2 (c)).

Click Here for Installation Instructions

Click Here for Drawing

Download Revit File here

SKU: N/A Categories: ,

Documentation

Stack ApplicationsDia.FRLReport No.
150mm+ Concrete Slab
PVC Pipe315-/180/180FSP1872
Wall ApplicationsDia.FRLReport No.
116mm+ Plasterboard Wall *
PVC Pipe315-/120/120FSP1931
HDPE Pipe315-/120/120FSP1946
FireCrunch MgO Board Wall
PVC Pipe315-/90/90FCO3268
HDPE Pipe315-/90/90FCO3268

* 2 x 13mm Fire-rated Plasterboard Sheets Either Side of 64mm Steel Stud. For Systems Approved on a 2 x 13mm Fire-rated Plasterboard Sheets One Side of 64mm Steel Stud and 25mm Shaft Liner on the Other, Refer to FCO3348

1 x 10mm Firecrunch MgO Board Either Side of 90mm Steel Stud. Contact Manufacturer for Wall System Details

Tested in Accordance with AS1530.4 & AS4072.1

NCC 2022 Compliant for the Above Uses

Product Specs

Element

, , , , , ,

Cast-In or Retrofit

Application

,

Pipe Type

, ,
