FCO3426 – Covers all the installation variations found on site, such as acoustic lagging, paint om collars, recessed collars, proximity to obstacles and many more.
FSP1673 – Snap FWS retro-fit collars under Snap stack cast-in collars.
FSP1715 – Snap 100 stack and 100 FWS collars cast into the side of a beam.
FSP1741 – Snap collars cast in a cluster.
FR5670 – Thermotec NuWrap 5 acoustic lagging hard up to base of collar, collar recessed to 50mm, unused collar back-filled with concrete.
FSP1830 – H100S-RR with 20mm bead of non-fire rated, neutral cure Roof and Gutter Silicone Sealant around pipe.
FSP1849 – Bundle of 3 x 20mm PEX-a pipes through an LP50R collar under a concrete slab.
FSP1872 – Bundle of 3 x 25mm PEX-b pipes through an H50FWS cast-in collar, bundle of 4 x 20mm PEX-b pipes through an H50FWS cast-in collar.
FSP1902 – PEX-b and PX-AL-PX pipe pairs through a single penetration on a fire-rated plasterboard wall.
FSP1906 – Fire-rated plasterboard ceiling penetrated by Rehau Raupiano pipes in floorwaste and stack applications, 60min RISF rating.
FRT190069 – Snap 50 & 150 stack collars cast into the side of a beam.
FSP2028 – PVC floorwaste incorporating a 4‐way riser completely covered in Soundlag 4525C acoustic lagging.
FSP2097 – Fire-rated plasterboard ceiling penetrated by PVC and PEX-a pipes in floorwaste and stack applications, 60min RISF rating.
FSP2116 – SuperTube BottomTurn Bend pushed all the the way up into a 110R and a H100S-RR
FCO3348 – Range of Snap retrofit collars on a shaft liner wall
FCO3396 – SuperTube Bottom Turn Bend, SoVent Fitting and HDPE Butt Welds inside a range of Snap collar
FSP2153 – Blanking off unused cast-in fire collars with a PVC plug
FSP2264 – Soundlag 4525C acoustic lagging hard up to base of H150S and H150FWS
FSP2274 – 110 Fuseal Floor Waste in a 180mm+ concrete slab through H100FWS w/ LP100R-D underneath
